AGCO DT180


AGCO DT180 tractor photo
2002 - 2004
DT Series
Row-Crop tractor
Series map:
DT160
DT180
DT200
177.8hp*
215.0hp
235.0hp
Production
ManufacturerAGCO
Row-Crop tractor
Built in Beauvais, France
AGCO DT180 Engine
Cummins 8.3L 6-cyl diesel
Fuel tank120 gal
454.2 L
Engine details ...
AGCO DT180 Power
Engine215 hp
160.3 kW
PTO (claimed)180 hp
134.2 kW
Drawbar (tested)160.22 hp
119.5 kW
PTO (tested)184.29 hp
137.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard.
Hydraulics
Typeclosed center pressure flow compensated (PFC)
Pressure2900 psi
200.0 bar
Valves4
Pump flow29 gpm
109.8 lpm
 39 gpmOptOptional
147.6 lpm
Tractor hitch
Rear Type3/3N
Rear lift (at 24"/610mm)18,000 lbs
8164 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
Dimensions & Tires
Wheelbase121 inches
307 cm
Weight18,500 lbs
8391 kg
Full dimensions and tires ...
DT180 Serial Numbers
2002L001001
2003M001001
2004N001001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
DT180 references literature
RT/DT Series - Ready to Rumble published in 2001, by AGCO
