AGCO ST47A
|
|
| Production | |
| Distributor | AGCO |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Built in Matsuyama, Japan | |
| AGCO ST47A Engine | |
| Iseki 2.2L 4-cyl diesel | |
 Engine details ... |
| AGCO ST47A Transmissions | |
| 8-speed synchro shuttle | |
| 12-speed power shuttle | |
| hydrostatic | |
| 12-speed four-speed power shift | |
 Transmission details ... |
| AGCO ST47A Power | |
| Engine (gross) | 47.5 hp 35.4 kW |
| Hydro PTO (claimed) | 36.5 hp 27.2 kW |
| Gear PTO (claimed) | 38 hp 28.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the AGCO ST47A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 11.6 gpm 43.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control with optional draft control |
| Rear lift (at ends) | 3483 lbs 1579 kg |
| Rear lift (at 24"/610mm) | 3086 lbs 1399 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 75 inches 190 cm |
| Weight | 3494 lbs 1584 kg |
 Full dimensions and tires ... | |
| AGCO ST47A attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| ST Series published in 2004, by AGCO | |
| ST Series published in 2004, by AGCO* | |
| *Publication contains known errors. |
