Mitsubishi MT200
| | 2000 - 2007 |
| MT Series | | Compact Utility tractor |
|
Series map:
MT200
MT260
14.9kw
19.4kw
| Production |
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Mitsubishi MT200 Power |
| Engine | 20 hp
14.9 kW
|
| PTO (claimed) | 17.5 hp
13.0 kW
|
| Mechanical |
| Drive | 4x2 2WD
|
| | 4x4 MFWD 4WD (MT200D)
|
| Steering | hydrostatic power
|
| Drum brakes |
| Two-post ROPS. |
| Hydraulics |
| Pressure | 2134 psi
147.1 bar
|
| Pump flow | 5.84 gpm
22.1 lpm
|
| Steering flow | 3.41 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control, draft control optional
|
| Rear lift (at ends) | 1400 lbs
635 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear PTO Type | 540/1000 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on January 31, 2013 |
©2000-2026 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
