Deutz-Allis 7120
| | 1986 - 1990 |
| 7100 Series | | Row-Crop tractor |
|
Series map:
7110
7120
7145
122.2hp*
135.6hp*
160.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Deutz-Allis
|
| Row-Crop tractor |
| The Deutz-Allis 7120 is similar to the Deutz-Fahr DX 6.50. |
| Deutz-Allis 7120 Power |
| PTO (claimed) | 122 hp
91.0 kW
|
| Drawbar (tested) | 101.36 hp
75.6 kW
|
| PTO (tested) | 122.06 hp
91.0 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | push-button rear
|
| | OPTICTRAC automatic front
|
| Steering | hydrostatic power
|
| Differential hydraulic dry disc brakes |
| Detuz-Allis MasterCab standard with heat and air-conditioning. Agrotronic instrumentation standard, optional Agrotronic II. |
| Capacity |
| Fuel | 40 gal
151.4 L
|
| | 66 galOptOptional
249.8 L
|
| Hydraulic system | 10 gal
37.9 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10 gal
37.9 L
|
| Pressure | 2538 psi
175.0 bar
|
| Valves | 1 to 3
|
| Pump flow | 14.8 gpm
56.0 lpm
|
| Total flow | 24 gpm
90.8 lpm
|
| Steering flow | 9.2 gpm
34.8 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift | 14,330 lbs
6500 kg
|
| Front Hitch | II OptOptional
|
| Front lift | 6,393 lbs
2899 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 90
|
| Charging volts | 14
|
| Batteries | 2
|
| Battery volts | 6
|
| References |
 |
| 7085/7110/7120/7145 published in 1986, by Deutz-Allis |
