New Holland row-crop TM155
| Production |
| Manufacturer: | New Holland
|
| Factory: | Basildon, England
|
| New Holland TM155 Power |
| Engine: | 155 hp
115.6 kW
|
| PTO (claimed): | 125 hp
93.2 kW
|
| Drawbar (tested): | 108.5 hp
80.9 kW
|
| PTO (tested): | 133.8 hp
99.8 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD optional
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab standard with heat and air-conditioning. Optional heated air-ride seat.
|
| Transmissions: | 17-speed full power shift
|
| | 18-speed full power shift
|
| | 17-speed partial power shift
|
| | 18-speed partial power shift
|
 Transmission details ... |
| Capacity |
| Fuel: | 75.3 gal
285.0 L
|
| Hydraulic system: | 5.95 gal
22.5 L
|
| Hydraulics |
| Type: | closed center load sensing (CCLS)
|
| Capacity: | 5.95 gal
22.5 L
|
| Pressure: | 2750 psi
189.6 bar
|
| Rear valves: | 4
|
| Mid valves: | 2 to 4
|
| Pump flow: | 28 gpm
106.0 lpm
|
| Total flow: | 44 gpm
166.5 lpm
|
| Steering flow: | 16 gpm
60.6 lpm
|
| Tractor hitch |
| Rear Type: | 2/3N
|
| Control: | electronic lower-link draft control
|
| Rear lift (at 24"/610mm): | 11,420 lbs
5180 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic wet disc
|
| Rear RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Battery CCA: | 1300
|
| Battery volts: | 12
|
