Tractors > New Holland > TS125A

New Holland TS125A



No photo available
2003 - 2007
TS-A Series
Utility tractor
Series map:
TS125A
TS135A
125.0hp
135.0hp
Production
ManufacturerNew Holland
Utility tractor
Built in Basildon, England
New Holland TS125A Engine
New Holland 6.7L 6-cyl diesel
Fuel tank58.1 gal
219.9 L
Engine details ...
New Holland TS125A Transmissions
24-speed two-speed power shift
16-speed four-speed power shift
Transmission details ...
New Holland TS125A Power
Engine125 hp
93.2 kW
PTO (claimed)105 hp
78.3 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Two-post foldable ROPS. Cab available with air-conditioning.
Photos
No photos of the New Holland TS125A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen
 closed load sensing OptOptional
Valves2 to 4
Pump flow26.5 gpm
100.3 lpm
Total flow37 gpm
140.0 lpm
Tractor hitch
Rear TypeII
 IIIN/II *Category 3 hitch available with electronic draft control.
Controlmechanical lower-link draft sensing
 electronic draft control OptOptional
Rear lift9285 lbs
4211 kg
 9620 lbs
4363 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Dimensions & Tires
2WD Wheelbase104.4 inches
265 cm
4WD Wheelbase104.7 inches
265 cm
Weight11,331 lbs
5139 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps70
Cab Charging amps120
Battery CCA1300
Battery volts12
