New Holland Boomer TZ18DA
| | 2003 - 2008 |
| Boomer TZ Series | | Sub-Compact Utility tractor |
|
Series map:
TZ18DA
TZ22DA
18.0hp
22.0hp
| Production |
| Manufacturer | New Holland
|
| Sub-Compact Utility tractor |
| New Holland TZ18DA Power |
| Engine (gross) | 18 hp
13.4 kW
|
| PTO (claimed) | 13.7 hp
10.2 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post ROPS. |
| Hydraulics |
| Type | open center
|
| Pump flow | 3.75 gpm
14.2 lpm
|
| Total flow | 5.6 gpm
21.2 lpm
|
| Steering flow | 1.85 gpm
7.0 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at 24"/610mm) | 700 lbs
317 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 540 (1.375)
|
| Mid PTO | standard
|
| Mid RPM | 2200
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 36
|
| Battery CCA | 325
|
| Battery volts | 12
|
| References |
 |
| BOOMER Tractor Implements, Attachments and Accessories published in 2005, by New Holland |
| BOOMER 18 To 55 HP Tractors published in 2005, by New Holland |
| Page information |
| Contact: Peter Easterlund |
| Updated on December 28, 2022 |
| Copyright 2023 TractorData LLC |
