Shibaura SE6300
|
|
| Production | |
| Manufacturer | Shibaura |
| Utility tractor | |
| Built in Matsumoto, Japan | |
| Shibaura SE6300 Engine | |
| Shibaura 3.4L 3-cyl diesel | |
 Engine details ... |
| Shibaura SE6300 Transmission | |
| 16-speed synchromesh | |
 Transmission details ... |
| Shibaura SE6300 Power | |
| Engine | 63 hp 47.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
| No photos of the Shibaura SE6300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 15.85 gal 60.0 L |
| Hydraulic system | 6.6 gal 25.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 6.6 gal 25.0 L |
| Pressure | 2900 psi 200.0 bar |
| Pump flow | 8.1 gpm 30.7 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/800/1000 |
| Engine RPM | 540@2200 |
| 800@2200 | |
| 1000@2200 | |
| Dimensions & Tires | |
| Wheelbase | 82.7 inches 210 cm |
| Weight | 5542 lbs 2513 kg |
| Front tire | 7.50-16 |
| Rear tire | 16.9-30 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| Battery AH | 150 |
| References | |
 | |
| SE5300 - SE6300 - SE7300T - SE8300 - SF1000T published in 1983, by Shibaura |
