Shibaura ST318



Shibaura ST318 tractor photo
ST Series
Compact Utility tractor
Series map:
ST318
ST321
18.0hp
21.0hp
Production
ManufacturerShibaura
Compact Utility tractor
Built in Matsumoto, Japan
Shibaura ST318 Engine
Shiabaura 1.0L 3-cyl diesel
Engine details ...
Shibaura ST318 Transmissions
9-speed gear
hydrostatic
Transmission details ...
Shibaura ST318 Power
Engine18 hp
13.4 kW
PTO (claimed)15 hp
11.2 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the Shibaura ST318 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel5.3 gal
20.1 L
Hydraulic system4.2 gal
15.9 L
Hydraulics
Typeopen center
Capacity4.2 gal
15.9 L
Pressure1849 psi
127.5 bar
Pump flow4 gpm
15.1 lpm
Tractor hitch
Rear TypeI
Rear lift1474 lbs
668 kg
Power Take-off (PTO)
Gear Rear PTOtransmission
Hydro Rear PTOlive
Rear PTO Type540 (1.375)
Gear Engine RPM588@2600
Hydro Engine RPM561@2600
Mid PTOoptional
Mid PTO Type2000
Gear Engine RPM2139@2600
Hydro Engine RPM2040@2600
Dimensions & Tires
Wheelbase55.3 inches
140 cm
Weight1625 to 1653 pounds
Front tire5-12
Rear tire8-16
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Charging volts14
Battery volts12
References
ST318 references literature
ST318 ST321 ST324 Workshop Manual
