Lamborghini Champion 120
|
|
| Production | |
| Manufacturer | Lamborghini |
| Row-Crop tractor | |
| Lamborghini Champion 120 Engine | |
| SDF 6.0L 6-cyl diesel | |
| Fuel tank | 60.8 gal 230.1 L |
| 100.4 galOptOptional 380.0 L | |
 Engine details ... | |
| Lamborghini Champion 120 Transmissions | |
| 18-speed 9-speed power shift | |
| 27-speed creeper | |
 Transmission details ... |
| Lamborghini Champion 120 Power | |
| Engine | 120 hp 89.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Lamborghini Champion 120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| load-sensing OptOptional | |
| Valves | 8 OptOptional |
| Pump flow | 19.3 gpm (open) 73.1 lpm |
| 27.2 gpm (load-sensing) 103.0 lpm | |
| Tractor hitch | |
| Rear lift | 15432 lbs 6999 kg |
| 18960 lbs*With optional lift cylinders. 8600 kg | |
| Front lift | 8818 lbsOptOptional 3999 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| 540E/1000 | |
| Front PTO | independent OptOptional |
| Clutch | electro-hydraulic |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 108.3 inches 275 cm |
| Weight | 13448 lbs 6100 kg |
| Front tire | 420/70R28 |
| Rear tire | 520/70R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| References | |
 | |
| Champion 120-135-150 published in 1999, by Lamborghini |
