Lamborghini 1506
| | 1984 - 1994 |
| Row-Crop tractor |
|
Series map:
1306
1506
1706
93.2kw
108.1kw
123.0kw
| Production |
| Manufacturer | Lamborghini (a part of SAME)
|
| Row-Crop tractor |
| Lamborghini 1506 Power |
| Engine | 145 hp
108.1 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| Cab available with air-conditioning. |
| Hydraulics |
| Pump flow | 16.7 gpm
63.2 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | position and draft control
|
| Rear lift | 11904 lbs
5399 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Charging system | alternator
|
| ROPS Charging amps | 45
|
| Cab Charging amps | 55
|
| Battery volts | 12
|
| Battery AH | 143
|
| References |
 |
| 1506 Turbo published in 1986, by Lamborghini |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 18, 2022 |
