Lamborghini 684


Lamborghini 684 tractor photo
1982 - 1985
Utility tractor
Series map:
653
684
51.5kw
53.7kw
Production
ManufacturerLamborghini
Utility tractor
Variants
684utility tractor
C684crawler
684Forchard
Lamborghini 684 Engine
SAME 3.6L 4-cyl diesel
Fuel tank17.2 gal
65.1 L
Engine details ...
Lamborghini 684 Transmissions
12-speed synchronized
16-speed creeper
Transmission details ...
Lamborghini 684 Power
Engine (gross)72 hp
53.7 kW
Engine (net)70 hp
52.2 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
Mechanical wet disc brakes
Four-post ROPS. Cab optional.
Photos
No photos of the Lamborghini 684 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow7.9 gpm
29.9 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift6614 lbs
3000 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
2WD Wheelbase89.2 inches
226 cm
4WD Wheelbase89.8 inches
228 cm
Weight5842 to 6393 pounds
Front tire7.50-16
2WD Rear tire16.9/14-30
Full dimensions and tires ...
Electrical
Charging systemalternator
Battery volts12
Battery AH110
References
684 references literature
684 published in 1983, by Lamborghini
