Volvo T430
| | 1969 - 1978 |
| Utility tractor |
|
| Production |
| Manufacturer: | Volvo
|
| Type: | Utility tractor
|
| Total built: | 23764
|
| Volvo T430 Power |
| Engine: | 42.5 hp
31.7 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | mechanical
|
| Cab: | Open operator station. Cab optional.
|
| Transmissions: | 8-speed gear
|
| | 16-speed two-speed power shift
|
 Transmission details ... |
| Hydraulics |
| Pump flow: | 8.7 gpm
32.9 lpm
|
| Tractor hitch |
| Rear lift: | 2756 lbs
1250 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@1770
|
| Page information |
| Last update: | March 5, 2020
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
