Volvo T36
|
|
| Production | |
| Manufacturer | Volvo |
| Row-Crop tractor | |
| Total built | 1632 |
| The Volvo T36 was the same as the Bolinder Munktell BM36. | |
| Volvo T36 Engine | |
| Bolinder 3.4L 3-cyl diesel | |
| Fuel tank | 17.2 gal 65.1 L |
 Engine details ... | |
| Volvo T36 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Volvo T36 Power | |
| Engine | 41.9 hp 31.2 kW |
| PTO (claimed) | 37.5 hp 28.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Volvo T36 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1500 |
| Dimensions & Tires | |
| Wheelbase | 79.1 inches 200 cm |
| Weight | 5424 lbs 2460 kg |
| Front tire | 6.00x19 |
| Rear tire | 11x38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | generator |
| Battery volts | 12 |
| References | |
 | |
| T35/36 published in 1957, by Volvo |
