Volvo T24
|
|
| Production | |
| Manufacturer | Volvo |
| Standard-tread tractor | |
| Volvo T24 Engine | |
| Volvo 2.2L 4-cyl kerosene | |
 Engine details ... |
| Volvo T24 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Volvo T24 Power | |
| Engine | 27.1 hp 20.2 kW |
| PTO (claimed) | 24.1 hp 18.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
| No photos of the Volvo T24 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 11.9 gal 45.0 L |
| Aux. fuel | 1 gal 3.8 L |
| Hydraulic system | 1.6 gal 6.1 L |
| Hydraulics | |
| Capacity | 1.6 gal 6.1 L |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1700 |
| Dimensions & Tires | |
| Wheelbase | 69.7 inches 177 cm |
| Weight | 3505 lbs 1589 kg |
| Front tire | 5.50-16 |
| Rear tire | 11-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | generator |
| Battery volts | 6 |
| Battery AH | 85 |
| References | |
 | |
| T24 published in 1953, by Volvo | |
| T24-T25 published in 1955, by Volvo | |
| Instruktionsbok Traktor T24-25 (SS 1076/1) published in 1952 |
