Volvo T22
|
|
| Production | |
| Manufacturer | Volvo |
| Standard-tread tractor | |
| Volvo T22 Engine | |
| Volvo 2.0L 4-cyl kerosene | |
| Fuel tank | 11.9 gal 45.0 L |
| Aux. fuel | 1 gal 3.8 L |
 Engine details ... | |
| Volvo T22 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Volvo T22 Power | |
| Engine | 22 hp 16.4 kW |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
| No photos of the Volvo T22 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1400 |
| Dimensions & Tires | |
| Wheelbase | 66.9 inches 169 cm |
| Weight | 2767 lbs 1255 kg |
| Front tire | 5.00-15 |
| Rear tire | 10-28 |
 Full dimensions and tires ... | |
| References | |
 | |
| T22 published in 1949, by Volvo |
