McCormick Intl CX105

McCormick Intl CX105 tractor photo
2003 - 2007
CX Series
Utility tractor
Manufacturer:McCormick Intl
Type:Utility tractor
Factory:Doncaster, England
McCormick Intl CX105 Power
Engine (net):102 hp
76.1 kW
Engine:102 hp
76.1 kW
PTO (claimed):83 hp
61.9 kW
Drawbar (tested):74 hp
55.2 kW
PTO (tested):86.2 hp
64.3 kW
power test details ...
McCormick Intl CX105 Engines
Perkins 4.0L 4-cyl diesel
Perkins 4.4L 4-cyl diesel
Engine details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Cab:ROPS. Cab optional.
Transmissions:24-speed partial power shift
 8-speed synchro shuttle
 16-speed partial power shift
Transmission details ...
Fuel:41 gal
155.2 L
Hydraulic system:9.1 gal
34.4 L (2WD)
 9.7 gal
36.7 L (4WD)
Type:open center
Capacity:9.1 gal
34.4 L (2WD)
 9.7 gal
36.7 L (4WD)
Pump flow:15.85 gpm
60.0 lpm
Tractor hitch
Rear lift:8,543 lbs
3875 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Engine RPM:540@2000
Dimensions & Tires
Wheelbase:92.9 inches
235 cm
Weight:8,280 lbs
3755 kg
Front tire:10.00-16
Rear tire:16.9R34
Full dimensions and tires ...
Charging system:alternator
Charging amps:65
Battery volts:12
