Fendt Farmer 250S


Fendt Farmer 250S tractor photo
1987 - 2002
Farmer 200 Series
Row-Crop tractor
Series:Farmer 240SFarmer 250SFarmer 260S
Production
Manufacturer:Fendt
Type:Row-Crop tractor
Variants
250S:2WD
Fendt Farmer 250S Power
Engine:49.3 hp
36.8 kW
Fendt Farmer 250S Engine
KHD 2.8L 3-cyl diesel
Fuel tank:15.9 gal
60.2 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic drum
Cab:Cab standard with heat. Air-conditioning optional.
Transmissions:21-speed
 21-speed shuttle
Transmission details ...
Photos
No photos of the Fendt Farmer 250S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2611 psi
180.0 bar
Pump flow:10.3 gpm
39.0 lpm
Tractor hitch
Rear lift:6151 lbs
2790 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/750/1000
Front RPM:1000
Dimensions & Tires
Wheelbase:80.7 inches
204 cm
Weight:5512 to 6063 pounds
Front tire:7.50-18
2WD Rear tire:14.9R30
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:55
Charging volts:14
Battery volts:12
Battery AH:88
