Fendt Farmer 106S
|
|
| Production | |
| Manufacturer | Fendt |
| Row-Crop tractor | |
| Fendt Farmer 106S Engines | |
| MWM 3.4L 4-cyl diesel | |
| MWM 4.2L 4-cyl diesel | |
| Fuel tank | 23.2 gal 87.8 L |
 Engine details ... | |
| Fendt Farmer 106S Transmissions | |
| 13-speed synchronized | |
| 16-speed creeper | |
 Transmission details ... |
| Fendt Farmer 106S Power | |
| Engine | 64.4 hp 48.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Cab standard. |
| Photos | |
 | |
 Fendt Farmer 106S photos... | |
| Tractor hitch | |
| Rear lift | 5688 lbs 2580 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 87.6 inches 222 cm |
| 4WD Wheelbase | 88.4 inches 224 cm |
| Weight | 6735 to 7650 pounds |
| Front tire | 7.50-18 |
| 2WD Rear tire | 13.6/12-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 28 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 110 |
| References | |
 | |
| Farmer Vierzylinder-Turbomatik published in 1977, by Fendt |
