SAME Diamond 260
|
|
| Production | |
| Manufacturer | SAME |
| Row-Crop tractor | |
| Variants | |
| Agrotron 260 | similar Deutz-Fahr model |
| Victory 260 | similar Lamborghini model |
| SAME Diamond 260 Engine | |
| SAME 7.1L 6-cyl diesel | |
| Fuel tank | 145.3 gal 550.0 L |
 Engine details ... | |
| SAME Diamond 260 Transmission | |
| 40-speed four-speed power shift | |
 Transmission details ... |
| SAME Diamond 260 Power | |
| Engine | 260 hp 193.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | pneumatic |
| hydraulic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the SAME Diamond 260 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Pump flow | 31.7 gpm 120.0 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 23149 lbs 10500 kg |
| Front Hitch | II OptOptional |
| Front lift | 11244 lbs 5100 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 1000 (1.75) |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 121.5 inches 308 cm |
| Weight | 18629 lbs 8450 kg |
| Front tire | 520/70R34 |
| Rear tire | 620/70R42 |
 Full dimensions and tires ... | |
| References | |
 | |
| Agrotron 230-260 published in 1998, by Deutz-Fahr | |
| Diamond 230 - 260 published in 1999, by SAME |
