Farmtrac 535
| | 2006 - 2008 |
| 5 Series | | Utility tractor |
|
Series map:
435
535
545
35.0hp
35.0hp
42.0hp
| Production |
| Manufacturer | Farmtrac (a part of Escorts)
|
| Utility tractor |
| Built in India |
| Farmtrac 535 Power |
| Engine | 35 hp
26.1 kW
|
| PTO (claimed) | 30 hp
22.4 kW
|
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Two-post folding ROPS. |
| Photos |
| No photos of the Farmtrac 535 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pump flow | 9 gpm
34.1 lpm
|
| Total flow | 14 gpm
53.0 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift | 3080 lbs
1397 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Clutch | dry disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1800
|
| Electrical |
| Charging amps | 35
|
| Battery CCA | 800
|
| Battery volts | 12
|
| References |
 |
| FarmTrac 435/535 published in 2006, by Long Agribusiness |
