Farmtrac 300
| | 2000 - 2005 |
| LandTrac Series | | Compact Utility tractor | | LS built |
|
Series map:
280
300
360
28.0hp
30.0hp
36.0hp
| Production |
| Distributor | Farmtrac (a part of Escorts)
|
| Manufacturer | LS
|
| Compact Utility tractor |
| Built in South Korea |
| Farmtrac 300 Power |
| Engine | 30 hp
22.4 kW
|
| PTO (claimed) | 26 hp
19.4 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the Farmtrac 300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Valves | 2
|
| Pump flow | 7.8 gpm
29.5 lpm
|
| Total flow | 11.9 gpm
45.0 lpm
|
| Steering flow | 4.1 gpm
15.5 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position and draft control
|
| Rear lift (at 24"/610mm) | 2976 lbs
1349 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2520
|
| 300 Serial Numbers |
| Location: | Serial number plate on the left side of the tractor frame, above the front axle.
|
| Electrical |
| Ground | negative
|
| Charging amps | 50
|
| Battery CCA | 600
|
| Battery volts | 12
|
| References |
 |
| 300DTC/360DTC published in 2005, by Farmtrac |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on July 15, 2026 |
