Yanmar YM135
|
|
| Production | |
| Manufacturer | Yanmar |
| Sub-Compact Utility tractor | |
| Original price was $4,400 in 1979 | |
| Variants | |
| YM135 | 2WD |
| YM135D | 4WD |
| Yanmar YM135 Engine | |
| Yanmar 0.6L 2-cyl diesel | |
 Engine details ... |
| Yanmar YM135 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Yanmar YM135 Power | |
| Engine | 13 hp 9.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. | |
| Photos | |
 | |
 Yanmar YM135 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 3.8 gpm 14.4 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 1210 lbs 548 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2540 |
| 770@2540 | |
| Front PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| 2WD Wheelbase | 45.7 inches 116 cm |
| 4WD Wheelbase | 48.9 inches 124 cm |
| Weight | 991 to 1090 pounds |
| Front tire | 4.50-10 |
| 2WD Rear tire | 7-16 |
 Full dimensions and tires ... | |
| Yanmar YM135 attachments | |
| 45" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| YFL-155TD Loaders published by Yanmar | |
| Service Manual Model YM135(D), YM155(D) (AOD1048) published in 1976 |
