AGCO Allis 9815
|
|
| Production | |
| Manufacturer | AGCO Allis |
| Row-Crop tractor | |
| Original price was $122,000 in 1998 | |
| AGCO Allis 9815 Engine | |
| Detroit Diesel 8.7L 6-cyl diesel | |
| Fuel tank | 91 gal 344.4 L |
 Engine details ... | |
| AGCO Allis 9815 Transmission | |
| 18-speed full power shift | |
 Transmission details ... |
| AGCO Allis 9815 Power | |
| PTO (claimed) | 215 hp 160.3 kW |
| Drawbar (tested) | 186.16 hp 138.8 kW |
| PTO (tested) | 229.21 hp 170.9 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
 | |
 AGCO Allis 9815 photos... | |
| Hydraulics | |
| Type | closed center |
| Pressure | 2750 psi 189.6 bar |
| Rear valves | 3 or 4 |
| Pump flow | 26 gpm 98.4 lpm |
| Tractor hitch | |
| Rear Type | III |
| Control | lower-link draft sensing |
| Rear lift (at 24"/610mm) | 14000 lbs 6350 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 1000 (1.75) |
| Dimensions & Tires | |
| Wheelbase | 115 inches 292 cm |
| Weight | 18100 to 19610 pounds |
| Front tire | 16.9R28 |
| Rear tire | 20.8R38 |
 Full dimensions and tires ... | |
| 9815 Serial Numbers | |
| Location: | Console, right side |
| 1994 | 901001 |
| 1995 | 901501 |
| 1996 | 902301 |
| 1997 | 902357 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| 9600/9800 Series Tractors published by AGCO |
