Tractors > AGCO Allis > 9775

AGCO Allis 9775 Tests



AGCO Allis 9775 tractor photo
1998 - 2001
9700 Series
Row-Crop tractor
Series map:
9765
9775
9785
200.0hp*
222.2hp*
250.0hp*
*Estimated engine power for comparison only.
Tractor Tests
NTTL 1794A: Navistar diesel 18-speed 4WD
OECD 1794: Cummins diesel 18-speed 4WD
Nebraska Tractor Test 1794A
9775 fuel use from test 1794A
Nebraska Tractor Test 1794A
Navistar diesel 18-speed 4WD
September 20 - 26, 2000
Link: Nebraska Tractor Test 1794A file
PTO performance
Max power220.67 hp
164.6 kW
Fuel use12.4 gal/hour
46.9 l/hour
Power at rated engine speed204.62 hp
152.6 kW
Fuel use12.5 gal/hour
47.3 l/hour
Power at rated PTO speed215.80 hp
160.9 kW
Fuel use12.5 gal/hour
47.3 l/hour
OCED Tractor Test 1794
9775 fuel use from test 354
OCED Tractor Test 1794
Cummins diesel 18-speed 4WD
May 7 - 18, 2001
Link: OCED Tractor Test 1794 file
PTO performance
Max power225.28 hp
168.0 kW
Fuel use13.5 gal/hour
51.1 l/hour
Power at rated engine speed204.33 hp
152.4 kW
Fuel use13.0 gal/hour
49.2 l/hour
Power at rated PTO speed221.42 hp
165.1 kW
Fuel use13.4 gal/hour
50.7 l/hour
Drawbar performance
Max power177.14 hp
132.1 kW
Fuel use13.0 gal/hour
49.2 l/hour
Gear 11 used for power test.
Max pull17996 lbs
8162 kg
Gear 6 used for pull test.
