AGCO Allis 9755 Tests
|
|
| Tractor Tests | |
| NTTL 1781A: Navistar diesel 18-speed 4WD | |
| OECD 1781: Cummins diesel 18-speed 4WD |
| Nebraska Tractor Test 1781A | |||
| |||
| Nebraska Tractor Test 1781A | |
| Navistar diesel 18-speed 4WD September 21 - 22, 2000 Link: Nebraska Tractor Test 1781A file | |
| PTO performance | |
| Max power | 174.25 hp 129.9 kW |
| Fuel use | 10.4 gal/hour 39.4 l/hour |
| Power at rated engine speed | 163.45 hp 121.9 kW |
| Fuel use | 10.9 gal/hour 41.3 l/hour |
| Power at rated PTO speed | 168.92 hp 126.0 kW |
| Fuel use | 10.5 gal/hour 39.7 l/hour |
| OCED Tractor Test 1781 | |||
| |||
| OCED Tractor Test 1781 | |
| Cummins diesel 18-speed 4WD September 7 - 27, 2000 Link: OCED Tractor Test 1781 file | |
| PTO performance | |
| Max power | 168.30 hp 125.5 kW |
| Fuel use | 10.5 gal/hour 39.7 l/hour |
| Power at rated engine speed | 164.38 hp 122.6 kW |
| Fuel use | 10.7 gal/hour 40.5 l/hour |
| Power at rated PTO speed | 168.30 hp 125.5 kW |
| Fuel use | 10.5 gal/hour 39.7 l/hour |
| Drawbar performance | |
| Max power | 142.58 hp 106.3 kW |
| Fuel use | 10.4 gal/hour 39.4 l/hour |
| Gear 10 used for power test. | |
| Max pull | 17894 lbs 8116 kg |
| Gear 5 used for pull test. | |
