AGCO Allis 9190
| | 1991 - 1992 |
| 9100 Series | | Row-Crop tractor | | White built |
|
Series map:
9170
9190
192.2hp*
214.4hp*
*Estimated engine power for comparison only.
| Production |
| Distributor | AGCO Allis
|
| Manufacturer | White
|
| Row-Crop tractor |
| Built in Coldwater, Ohio, USA |
| Original price was $90,200 in 1992 |
| AGCO Allis 9190 Power |
| Drawbar (claimed) | 173 hp
129.0 kW
|
| PTO (claimed) | 193 hp
143.9 kW
|
| Drawbar (tested) | 170.30 hp
127.0 kW
|
| PTO (tested) | 193.55 hp
144.3 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the AGCO Allis 9190 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 2 or 3
|
| Pump flow | 24 gpm
90.8 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | position and draft control
|
| Rear lift (at ends) | 9898 lbs
4489 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Engine RPM | 1000@2168
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 105
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| 9100 Series published in 1991, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on March 21, 2022 |
