Deutz-Fahr Agroplus 100
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr Agroplus 100 Engine | |
| Deutz 4.8L 6-cyl diesel | |
| Fuel tank | 37 gal 140.0 L |
 Engine details ... | |
| Deutz-Fahr Agroplus 100 Transmissions | |
| 30-speed | |
| 45-speed three-speed power shift | |
 Transmission details ... |
| Deutz-Fahr Agroplus 100 Power | |
| Engine | 99 hp 73.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Wet disc brakes | |
| Cab standard with available air-conditioning. | |
| Photos | |
| No photos of the Deutz-Fahr Agroplus 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2683 psi 185.0 bar |
| Pump flow | 14.8 gpm 56.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | lower-link draft sensing |
| Rear lift | 14330 lbs 6500 kg |
| Front Hitch | II OptOptional |
| Front lift | 6614 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 (1.375) |
| Engine RPM | 1000@2100 |
| Dimensions & Tires | |
| Wheelbase | 101.1 inches 256 cm |
| Weight | 9259 lbs 4199 kg |
| Front tire | 13.6R28 |
| Rear tire | 16.9R38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Agroplus 75 85 95 100 published in 1998, by Deutz-Fahr | |
| Agroplus 85 100 published in 1997, by Deutz-Fahr |
