Deutz-Fahr DX 4.50
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr DX 4.50 Engine | |
| Deutz 4.1L 4-cyl diesel | |
| Fuel tank | 31.7 gal 120.0 L |
 Engine details ... | |
| Deutz-Fahr DX 4.50 Transmissions | |
| 15-speed synchronized | |
| 20-speed creeper | |
 Transmission details ... |
| Deutz-Fahr DX 4.50 Power | |
| Engine | 80.5 hp 60.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic drum brakes |
| Photos | |
| No photos of the Deutz-Fahr DX 4.50 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2538 psi 175.0 bar |
| Pump flow | 10.6 gpm 40.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 11465 lbs 5200 kg |
| Front Hitch | II |
| Front lift | 3968 lbs 1799 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 91.7 inches 232 cm |
| 4WD Wheelbase | 94.5 inches 240 cm |
| Weight | 8069 to 8796 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 16.9-38 |
 Full dimensions and tires ... | |
| References | |
 | |
| DX4 published in 1984, by Deutz-Fahr |
