Deutz-Fahr DX 140
| | 1978 - 1983 |
| DX Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Deutz-Fahr
|
| Type: | Row-Crop tractor
|
| Deutz-Fahr DX 140 Power |
| PTO (claimed): | 131 hp
97.7 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | planetary
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | 24-speed
|
 Transmission details ... |
| Photos |
| No photos of the Deutz-Fahr DX 140 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2485 psi
171.3 bar
|
| Pump flow: | 18.0 gpm
68.1 lpm
|
| Tractor hitch |
| Rear Type: | III/II
|
| Rear lift (at ends): | 11921 lbs
5407 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | wet disc
|
| Rear RPM: | 1000 (1.75)
|
| | 540/1000*Sales literature lists a optional shiftable PTO, but the option appears to be rare.
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | May 20, 2016
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
