Tractors > Fiat > 160-90

Fiat 160-90 Transmission



Fiat 160-90 tractor photo
1984 - 1994
90 Series
Row-Crop tractor
Series map:
140-90
160-90
180-90
104.4kw
119.3kw
134.2kw
Transmission options
24-speed partial power shift
16-speed mechanical shuttle
Transmission
Typepartial power shift
Gears24 forward and 8 reverse
Clutchhydraulic wet disc
Four power-shift gears (1-4) in three forward ranges (low, medium, high) plus reverse range. Additional creeper mode doubles available ranges.
Speeds
With 18.4/15-38 rear tires.
160-90 partial power shift speeds
Transmission
Typemechanical shuttle
Gears16 forward and reverse
Clutch305mm dry disc
Oil capacity59.1 qts
55.9 L
Speeds
With 23.1-34 rear tires.
160-90 mechanical shuttle speeds
