John Deere 6110
| | 1999 - 2002 |
| 6000 TEN Series | | Utility tractor |
|
Series map:
6110
6210
84.0hp
90.0hp
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| Built in Mannheim, Baden-Württemberg, Germany |
| John Deere 6110 Engine |
| John Deere 4.5L 4-cyl diesel |
| Fuel tank | 30.7 gal*Standard on ROPS-equipped tractors. Optional on cab tractors.
116.2 L
|
| | 43.6 gal*Standard on cab tractors. Optional on ROPS tractors.
165.0 L
|
 Engine details ... |
| John Deere 6110 Power |
| Engine (gross) | 84 hp
62.6 kW
|
| PTO (claimed) | 65 hp
48.5 kW
|
| Drawbar (tested) | 61.9 hp
46.2 kW
|
| PTO (tested) | 71.1 hp
53.0 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Differential hydraulic wet disc brakes |
| Two-post ROPS. ComfortGard cab optional with air-conditioning. |
| Hydraulics |
| Type | closed center pressure-flow compensating
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 1 to 4
|
| Pump flow | 25.4 gpm
96.1 lpm
|
| | 18.9 gpmOptOptional
71.5 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | electronic lower-link draft sensing
|
| Rear lift | 4745 lbs
2152 kg
|
| Front Hitch | optional
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| | 540/1000 (1.375)OptOptional
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 90
|
| Cab Charging amps | 115
|
| Battery CCA | 830
|
| | 1230 OptOptional
|
| Battery volts | 12
|
| Battery AH | 110
|
| | 154 OptOptional
|
| References |
 |
| 6000 TEN Series published in 1998, by John Deere |
| 6000 TEN Series and Advantage Series Tractors published in 1998, by John Deere |
| 6000 TEN Series Tractors and Advantage Series Tractors Product Information Handbook published in 1998, by John Deere |
