Kubota M5040
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M5040 Engine | |
| Kubota 3.0L 4-cyl diesel | |
| ROPS Fuel tank | 18.5 gal 70.0 L |
| Cab Fuel tank | 29.1 gal 110.1 L |
 Engine details ... | |
| Kubota M5040 Transmissions | |
| 8-speed synchronized shuttle | |
| 8-speed power shuttle | |
| 12-speed creeper | |
 Transmission details ... |
| Kubota M5040 Power | |
| Engine (net) | 50.5 hp 37.7 kW |
| PTO (claimed) | 45 hp 33.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post ROPS with optional canopy. Ultra Grand Cab optional with heat and air-conditioning | |
| Photos | |
 | |
 Kubota M5040 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2770 psi 191.0 bar |
| Valves | 1 to 2 |
| Pump flow | 11 gpm 41.6 lpm |
| Steering flow | 6.1 gpm 23.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 3307 lbs 1500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2160 |
| Dimensions & Tires | |
| 4WD ROPS Wheelbase | 80.7 inches 204 cm |
| 2WD ROPS Wheelbase | 82.1 inches 208 cm |
| 4WD Cab Wheelbase | 83.1 inches 211 cm |
| 2WD Cab Wheelbase | 84.4 inches 214 cm |
| Weight | 3748 to 4553 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| Kubota M5040 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| ROPS Charging amps | 45 |
| Cab Charging amps | 60 |
| Battery CCA | 900 |
| Battery volts | 12 |
| References | |
 | |
| M5040/M6040/M7040/M8540/M9540 published in 2005, by Kubota | |
| New Product Guide M-Series Tractors published in 2005, by Kubota |
