Zetor 7711
|
|
| Production | |
| Manufacturer | Zetor |
| Built in Brno, Czechoslovakia | |
| Original price | $16500 (1992) |
| Zetor 7711 Engine | |
| Zetor 3.9L 4-cyl diesel | |
| Fuel tank | 18.5 gal 70.0 L |
 Engine details ... | |
| Zetor 7711 Transmission | |
| 10-speed partially synchronized | |
 Transmission details ... |
| Zetor 7711 Power | |
| Engine | 81 hp 60.4 kW |
| Drawbar (claimed) | 58 hp 43.3 kW |
| PTO (claimed) | 66 hp 49.2 kW |
| 75 hp (turbo) 55.9 kW | |
| Drawbar (tested) | 55.87 hp 41.7 kW |
| PTO (tested) | 65.74 hp 49.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Steering | power assist |
| Differential hydraulic dry disc brakes | |
| Photos | |
 | |
 Zetor 7711 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2,321 psi 160.0 bar |
| Valves | 2 |
| Total flow | 7.9 gpm 29.9 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 5300 lbs 2404 kg |
| Front Hitch | II OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 87.5 inches 222 cm |
| Weight | 6900 lbs 3129 kg |
| Front tire | 6.50-16 |
| Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| 7711 Serial Numbers | |
| Location: | Serial number plate on the right side of the dashboard. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| References | |
 | |
| Owner's Instruction Manual 5211, 5245, 6211, 6245, 7211, 7245, 7711 and 7745 | |
| 7711 - 7745 published by Zetor |
