Zetor 3341
| | 1997 - 2005 |
| Range 1 Super Series | | Utility tractor |
|
Series map:
3321
3341
4321
46.0hp
46.0hp
59.0hp
| Production |
| Manufacturer | Zetor
|
| Utility tractor |
| Built in Brno, Czech Republic |
| Zetor 3341 Power |
| Engine | 46 hp
34.3 kW
|
| PTO (claimed) | 43 hp
32.1 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the Zetor 3341 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 2600 psi
179.3 bar
|
| Valves | 1 to 3
|
| Pump flow | 14 gpm
53.0 lpm
|
| Steering flow | 4 gpm
15.1 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position and draft control
|
| Rear lift | 4300 lbs
1950 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 75
|
| Battery volts | 12
|
| References |
 |
| 3321 - 3341 published by Zetor |
| Super Series Tractors published by Zetor |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 28, 2018 |
