Tractors > County > FC 1004

County FC 1004



County FC 1004 tractor photo
1966 - 1975
Production
ManufacturerCounty
Built in Fleet, England
County FC 1004 Engine
Ford 5.9L 6-cyl diesel
Engine details ...
County FC 1004 Transmission
8-speed gear
Transmission details ...
County FC 1004 Power
Engine102 hp
76.1 kW
PTO (claimed)67 hp
50.0 kW
Mechanical
Drive4x4 4WD
Final drivesoutboard planetary
Differential lockmechanical front and rear
Power steering
Hydraulic wet disc brakes
Cab standard.
Photos
No photos of the County FC 1004 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel31.2 gal
118.1 L
Steering0.6 qts
0.6 L
Hydraulics
Typeopen center
Pressure2500 psi
172.4 bar
Pump flow6.3 gpm
23.8 lpm
Steering flow4.3 gpm
16.3 lpm
Steering cap.0.6 qts
0.6 L
Steering press.650 psi
44.8 bar
Tractor hitch
Rear TypeII
Rear lift3800 lbs
1723 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type540 (1.375)
Engine RPM540@1900
Dimensions & Tires
Wheelbase71.6 inches
181 cm
Weight9394 lbs
4261 kg
Front tire13.6/12-38
Rear tire13.6/12-38
Full dimensions and tires ...
References
FC 1004 references literature
Forward Control published in 1973, by County
