CaseIH MXM130 Maxxum


CaseIH MXM130 Maxxum tractor photo
2002 - 2007
Maxxum Series
Row-Crop tractor
MX135
Series:MXM120MXM130 MaxxumMXM140
Production
Manufacturer:CaseIH
Type:Row-Crop tractor
Factory:Basildon, England
CaseIH MXM130 Power
Engine:129 hp
96.2 kW
PTO (claimed):105 hp
78.3 kW
PTO (tested):113.3 hp
84.5 kW
power test details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD optional
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Transmission:18-speed partial powershift
Transmission details ...
Photos
No photos of the CaseIH MXM130 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:75 gal
283.9 L
Hydraulic system:23.75 gal
89.9 L
Hydraulics
Type:closed-center load sensing
Capacity:23.75 gal
89.9 L
Pressure:2750 psi
189.6 bar
Valves:2 to 5
Pump flow:25 gpm
94.6 lpm
Total flow:28 gpm
106.0 lpm (implement pump)
 44 gpm
166.5 lpm (total)
Tractor hitch
Rear Type:II
Control:electronic lower-link sensing
Rear lift (at 24"/610mm):8,725 lbs
3957 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/1000 (1.375)
Dimensions & Tires
Wheelbase:108.1 inches
274 cm
 107.2 inches
272 cm (4WD)
Weight:11,915 lbs
5404 kg
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:120
Battery CCA:1300
Battery volts:12
Battery AH:176
