John Deere 3320


John Deere 3320 tractor photo
2005 - 2013
3000 Twenty Series
Compact Utility tractor
Series map:
3120
3320
3520
29.5hp
32.5hp
37.0hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 3320 Transmissions
12-speed partially synchronized with power shuttle
hydrostatic
Transmission details ...
John Deere 3320 Power
Engine32.5 hp
24.2 kW
PTO (claimed)25 hp
18.6 kW
Mechanical
Four-wheel drive
Steeringpower
Wet disc brakes
Two-post foldable ROPS. Cab optional.
Capacity
ROPS Fuel13.5 gal
51.1 L
Cab Fuel11.8 gal
44.7 L
Hydraulic system6.8 gal
25.7 L
 6.3 gal (with gear transmission)
23.8 L
Hydraulics
Typeopen center
Capacity6.8 gal
25.7 L
 6.3 gal (with gear transmission)
23.8 L
Valves5
Pump flow8.6 gpm
32.6 lpm
Total flow13.9 gpm
52.6 lpm
Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)2530 lbs
1147 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Mid PTOoptional
Mid PTO Type2100
Dimensions & Tires
Wheelbase68 inches
172 cm
Weight2900 to 3570 pounds
Front tire7-14
Rear tire11.2-24
Full dimensions and tires ...
John Deere 3320 attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
3320 Serial Numbers
2005100001 (hydro)
2006230001 (hydro)
2007330001 (hydro)
2008420001 (hydro)
2009500001 (hydro)
2010600001 (hydro)
2011710001 (hydro)
2012810001 (hydro)
2013910001 (hydro)
2005100001 (gear)
2006240001 (gear)
2007340001 (gear)
2008427001 (gear)
2009504001 (gear)
2010604001 (gear)
2011710001 (gear)
2012810001 (gear)
2013910001 (gear)

FAQ: How to read a serial number table.
Electrical
Groundnegative
ROPS Charging amps40
Cab Charging amps75
Battery CCA500
Battery volts12
References
3320 references literature
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
3000 Series published in 2008, by John Deere
3000 Series published in 2009, by John Deere
3000 Twenty Series Compact Tractors published in 2005, by John Deere
3000 Twenty Series Tractors Product Information Handbook published in 2004, by John Deere
TWENTY Series Tractors published in 2010, by John Deere
Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere
