Belarus 922
|
|
| Production | |
| Manufacturer | Belarus |
| Row-Crop tractor | |
| Built in Minsk, Belarus | |
| Original price was $23,000 in 1993 | |
| Belarus 922 Engine | |
| Belarus 4.7L 4-cyl diesel | |
 Engine details ... |
| Belarus 922 Transmission | |
| 18-speed gear | |
 Transmission details ... |
| Belarus 922 Power | |
| Engine | 100 hp 74.6 kW |
| PTO (claimed) | 88 hp 65.6 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Disc brakes | |
| Cab standard with heat. | |
| Photos | |
 | |
 Belarus 922 photos... | |
| Capacity | |
| Fuel | 34.3 gal 129.8 L |
| Hydraulic system | 5.4 gal 20.4 L |
| Steering | 6.3 qts 6.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 5.4 gal 20.4 L |
| Pressure | 2274 psi 156.8 bar |
| Valves | 2 |
| Pump flow | 11.8 gpm 44.7 lpm |
| Steering cap. | 6.3 qts 6.0 L |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 4400 lbs 1995 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2068 |
| 1000@2158 | |
| Dimensions & Tires | |
| Wheelbase | 96.5 inches 245 cm |
| Weight | 7870 lbs 3569 kg |
| Front tire | 11.2-20 |
| Rear tire | 15.5-38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Operators Manual 500 Series, 800 Series and 900 Series Tractors (904805) published in 1992 | |
| 922 published by Belarus* | |
| *Publication contains known errors. |
