Belarus 505
|
|
| Production | |
| Manufacturer | Belarus |
| Built in Minsk, Belarus | |
| Variants | |
| 525 | 4WD |
| Belarus 505 Engine | |
| MTZ 4.8L 4-cyl diesel | |
 Engine details ... |
| Belarus 505 Transmission | |
| 9-speed unsynchronized | |
 Transmission details ... |
| Belarus 505 Power | |
| Engine | 65 hp 48.5 kW |
| PTO (claimed) | 59 hp 44.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Mechanical disc brakes |
| Photos | |
 | |
 Belarus 505 photos... | |
| Capacity | |
| Fuel | 34 gal 128.7 L |
| Hydraulic system | 4.5 gal 17.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 4.5 gal 17.0 L |
| Pressure | 2850 psi 196.5 bar |
| Valves | 2 |
| Pump flow | 9 gpm 34.1 lpm |
| Steering flow | 5.5 gpm 20.8 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 3325 lbs 1508 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/ground |
| Dimensions & Tires | |
| Wheelbase | 93.5 inches 237 cm |
| Weight | 7980 lbs 3619 kg |
| Front tire | 7.50-20 |
| Rear tire | 15.5-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Batteries | 2 |
| Battery CCA | 900 |
| Battery volts | 6 |
| References | |
 | |
| Operators Manual 500 Series, 800 Series and 900 Series Tractors (904805) published in 1992 |
