Kubota M8580
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M8580 Engine | |
| Kubota 4.7L 4-cyl diesel | |
| Fuel tank | 27.7 gal 104.8 L |
 Engine details ... | |
| Kubota M8580 Transmissions | |
| 12-speed power shuttle | |
| 12-speed mechanical shuttle | |
 Transmission details ... |
| Kubota M8580 Power | |
| Engine (net) | 85 hp 63.4 kW |
| PTO (claimed) | 80 hp 59.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Four-post ROPS. Cab optional. |
| Photos | |
 | |
 Kubota M8580 photos... | |
| Hydraulics | |
| Type | open center |
| Valves | 2 or 3 |
| Pump flow | 21.1 gpm 79.9 lpm |
| Total flow | 29.6 gpm 112.0 lpm |
| Steering flow | 8.5 gpm 32.2 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 5809 lbs 2634 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 96.1 inches 244 cm |
| Weight | 8377 lbs 3799 kg |
| Front tire | 13.6-24 |
| Rear tire | 18.4-34 |
 Full dimensions and tires ... | |
| Kubota M8580 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Front Loaders B, L and M-Series published in 1994, by Kubota* | |
| Mid-Size Tractor M7580/M8580/M9580 published in 1993, by Kubota | |
| *Publication contains known errors. |
