Kubota L285
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Kubota L285 Engine | |
| Kubota 1.5L 4-cyl diesel | |
| Fuel tank | 9.2 gal 34.8 L |
 Engine details ... | |
| Kubota L285 Transmission | |
| 8-speed gear | |
 Transmission details ... |
| Kubota L285 Power | |
| Engine | 30 hp 22.4 kW |
| PTO (claimed) | 26.5 hp 19.8 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Open operator station. | |
| Photos | |
 | |
 Kubota L285 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 4.7 gpm 17.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 2535 lbs 1149 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2070 |
| 1000@2105 | |
| Front PTO | independent |
| Clutch | elecro-magnetic |
| Dimensions & Tires | |
| Wheelbase | 67 inches 170 cm |
| Weight | 2230 lbs 1011 kg |
| Front tire | 5.00-15 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Kubota L285 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| New Model L285 published in 1975, by Kubota | |
| Diesel L285 Tractor published in 1978, by Kubota |
