Tractors > CaseIH > 5250 Maxxum

CaseIH 5250 Maxxum Tests



CaseIH 5250 Maxxum tractor photo
1992 - 1997
Maxxum Series
Series map:
5240
5250
111.1hp*
124.4hp*
*Estimated engine power for comparison only.
OCED Tractor Test 1462
5250 Maxxum fuel use from test 145
OCED Tractor Test 1462
Diesel 16-speed 4WD
January 1993 - March 1993,
Link: OCED Tractor Test 1462 file
PTO performance
Max power115.6 hp
86.2 kW
Fuel use6.8 gal/hour
25.7 l/hour
Power at rated engine speed112.20 hp
83.7 kW
Fuel use6.9 gal/hour
26.1 l/hour
Drawbar performance
Max power103.40 hp
77.1 kW
Fuel use6.8 gal/hour
25.7 l/hour
Max pull18295 lbs
8298 kg
