Nuffield 4/60
|
|
| Production | |
| Manufacturer | Nuffield |
| Built in Birmingham, England | |
| Nuffield 4/60 Engine | |
| BMC 3.8L 4-cyl diesel | |
| Fuel tank | 16.8 gal 63.6 L |
 Engine details ... | |
| Nuffield 4/60 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Nuffield 4/60 Power | |
| Engine (gross) | 60 hp 44.7 kW |
| Engine (net) | 57 hp 42.5 kW |
| Drawbar (claimed) | 50 hp 37.3 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Belt (claimed) | 56 hp 41.8 kW |
| Drawbar (tested) | 49.72 hp 37.1 kW |
| PTO (tested) | 54.90 hp 40.9 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Manual steering | |
| Independent mechanical expanding shoe brakes | |
| Open operator station. | |
| Photos | |
 | |
 Nuffield 4/60 photos... | |
| Hydraulics | |
| Type | open center |
| Tractor hitch | |
| Rear Type | II/I |
| Control | depth control OptOptional |
| Rear lift | 2300 lbs 1043 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 528@1400 |
| Dimensions & Tires | |
| Wheelbase | 78 inches 198 cm |
| Weight | 5689 lbs 2580 kg |
| Front tire | 6.00-16 |
| Rear tire | 11.00-36 |
 Full dimensions and tires ... | |
| Belt Pulley | |
| Diameter | 10.25 inches 26 cm |
| RPM | 1150 |
| Speed | 3160 ft/min 963.17 meters/min |
| References | |
 | |
| 4 60 published in 1961, by Nuffield |
