Steiger Cougar IV KS-280


Steiger Cougar IV KS-280 tractor photo
1984 - 1985
IV Series
Four-wheel Drive (4WD) tractor
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Variants
CS-280Cat Engine
KS-280Cummins engine
Steiger Cougar IV KS-280 Engine
Cummins 14.0L 6-cyl diesel
Fuel tank225 gal
851.6 L
Engine details ...
Steiger Cougar IV KS-280 Power
Engine280 hp
208.8 kW
Drawbar (claimed)224 hp
167.0 kW
Mechanical
Four-wheel drive
Final drivesoutboard planetary
Articulated power steering
Hydraulic disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Steiger Cougar IV KS-280 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2250 psi
155.1 bar
Valves3 to 5
Pump flow28.6 gpm
108.3 lpm
Tractor hitch
Rear TypeIII OptOptional
Dimensions & Tires
Wheelbase132.5 inches
336 cm
Weight25902 lbs
11749 kg
Front tire18.4-38
Rear tire18.4-38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Batteries4
Battery volts12
References
Cougar IV KS-280 references literature
Cougar IV Steigermatic published in 1983
The Steiger Line published in 1983
Cougar IV/Panter IV Steigermatic published in 1984
