Steiger Panther III ST-350


Steiger Panther III ST-350 tractor photo
1977 - 1981
III Series
Four-wheel Drive (4WD) tractor
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $94,700 in 1981
Steiger Panther III ST-350 Power
Engine350 hp
261.0 kW
Drawbar (claimed)311 hp
231.9 kW
Mechanical
Four-wheel drive
Final drivesoutboard planetary
Articulated power steering
Hydraulic disc brakes
Safari Cab standard with heat and air-conditioning.
Photos
No photos of the Steiger Panther III ST-350 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel267 gal
1010.6 L
Hydraulic system33 gal
124.9 L
Hydraulics
Typeopen center
Capacity33 gal
124.9 L
Pressure2250 psi
155.1 bar
Valves4
Pump flow30.1 gpm
113.9 lpm
Tractor hitch
Rear TypeIII OptOptional
Dimensions & Tires
Wheelbase128 inches
325 cm
Weight26700 lbs
12111 kg
Front tire20.8-34
Rear tire20.8-34
Full dimensions and tires ...
Panther III ST-350 Serial Numbers
1977139-00001
1978139-00011
1979139-00031
1980139-00061
1981139-00069

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Batteries2
Battery volts12
Battery AH208
Battery Group8D
References
Panther III ST-350 references literature
ST Tractors - Cummins Powered Series III Cougar ST 251, Panther ST 310 and Panther ST 350 published in 1979, by Steiger
ST Tractors - Cummins Powered Series III Cougar ST 251, Panther ST 310 and Panther ST 350 published in 1979, by Steiger
