Steiger Bearcat III ST-220
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| Original price was $48,000 in 1977 | |
| Steiger Bearcat III ST-220 Engine | |
| Cummins 14.0L 6-cyl diesel | |
| Fuel tank | 267 gal 1010.6 L |
 Engine details ... | |
| Steiger Bearcat III ST-220 Power | |
| Engine | 220 hp 164.1 kW |
| Drawbar (claimed) | 175 hp 130.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Safari Cab standard. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2250 psi 155.1 bar |
| Valves | 3 |
| Pump flow | 27.2 gpm 103.0 lpm |
| SCV flow | 20 gpm 75.7 lpm |
| Tractor hitch | |
| Rear Type | III OptOptional |
| Rear lift | 9500 lbs 4309 kg |
| Dimensions & Tires | |
| Wheelbase | 128 inches 325 cm |
| Weight | 21400 to 24135 pounds |
| Front tire | 23.1-30 |
| Rear tire | 23.1-30 |
 Full dimensions and tires ... | |
| Bearcat III ST-220 Serial Numbers | |
| 1976 | 103-00001 |
| 1977 | 103-00187 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| Batteries | 2 |
| Battery volts | 12 |
| Battery AH | 208 |
| Battery Group | 8D |
| References | |
 | |
| Operator's Manual Bearcat III ST220 (37-047) | |
| Series III published in 1976, by Steiger |
