Steiger 1700
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Red Lake Falls, Minnesota, USA | |
| Steiger 1700 Engine | |
| Detroit Diesel 5.2L 6-cyl diesel | |
 Engine details ... |
| Steiger 1700 Power | |
| Engine | 195 hp 145.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Articulated power steering | |
| Drum brakes | |
| Open operator station. Cab available. | |
| Photos | |
| No photos of the Steiger 1700 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 120 gal 454.2 L |
| Hydraulic system | 44 gal 166.5 L |
| Hydraulics | |
| Type | open center |
| Capacity | 44 gal 166.5 L |
| Valves | 2 |
| Total flow | 35 gpm 132.5 lpm |
| Dimensions & Tires | |
| Wheelbase | 126 inches 320 cm |
| Weight | 18300 lbs 8300 kg |
| Front tire | 18.4-30 |
| Rear tire | 18.4-30 |
 Full dimensions and tires ... | |
| References | |
 | |
| Red 4WD Tractors: 1957-2017 by Lee Klancher | |
| Red Book 1965 published by Implement & Tractor | |
| Red Book 1967 published by Implement & Tractor | |
| Red Book 1968 published by Implement & Tractor | |
| Red Book 1969 published by Implement & Tractor | |
| Ultimate Tractor Power: Articulated Tractors of the World, Volume 2 by Peter Simpson* | |
| Steiger Identification Guide: 1969-1998 published by Case IH | |
| All-Wheel Power published in 1966, by Steiger | |
| All-Wheel Drive Agricultural Tractors published in 1968, by Steiger | |
| Extra Heavy-Duty All-Wheel Drive Agricultural Tractors published in 1969, by Steiger | |
| *Publication contains known errors. |
