Minneapolis-Moline G850
| | 1971 - 1972 |
| Row-Crop tractor |
|
Series map:
G750
G850
77.8hp*
95.6hp*
*Estimated engine power for comparison only.
Note: the Minneapolis-Moline model G850 is the same as the Oliver 1755. The following data is from the 1755 listing. |
| Production |
| Manufacturer | Minneapolis-Moline (a part of White)
|
| Row-Crop tractor |
| Original price was $11,500 in 1975 |
| Minneapolis-Moline G850 Power |
| PTO (claimed) | 86 hp
64.1 kW
|
| Drawbar (tested) | 73.87 hp
55.1 kW
|
| PTO (tested) | 86.93 hp
64.8 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Differential hydraulic dry disc brakes |
| Open operator station. Optional two-post ROPS and cab. |
| Capacity |
| Fuel | 35 gal
132.5 L
|
| Hydraulic system | 6.75 gal
25.5 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 6.75 gal
25.5 L
|
| Pressure | 2200 psi
151.7 bar
|
| Pump flow | 20 gpm
75.7 lpm
|
| Tractor hitch |
| Rear Type | I/II
|
| | II/III OptOptional
|
| Rear lift | 4,000 lbs
1814 kg
|
| | 6,000 lbs (Cat 3)
2721 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| | 1000
|
| References |
 |
| Models G850/G940 published in 1971, by Minneapolis-Moline |
| Technical Service Manual 55 Series Tractor Engines (432618) published in 1973 |
| Technical Service Manual 55 Series Tractor Hydraulics (432616) published in 1973 |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on October 9, 2025 |
