Minneapolis-Moline U-302 Tests
|
|
| Nebraska Tractor Test 862 | |||
| |||
| Nebraska Tractor Test 862 | |
| Gasoline 10-speed 2WD April 10 - 24, 1964 Link: Nebraska Tractor Test 862 file | |
| PTO performance | |
| Power at rated engine speed | 55.82 hp 41.6 kW |
| Fuel use | 4.9 gal/hour 18.5 l/hour |
| Power at rated PTO speed | 48.51 hp 36.2 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Drawbar performance | |
| Max power | 46.89 hp 35.0 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Gear 2H used for power test. | |
| Max pull | 7417 lbs 3364 kg |
| Gear 1L used for pull test. | |
| Nebraska Tractor Test 863 | |||
| |||
| Nebraska Tractor Test 863 | |
| LP-gas 10-speed 2WD April 13 - 24, 1964 Link: Nebraska Tractor Test 863 file | |
| PTO performance | |
| Power at rated engine speed | 55.69 hp 41.5 kW |
| Fuel use | 5.8 gal/hour 22.0 l/hour |
| Power at rated PTO speed | 48.32 hp 36.0 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Drawbar performance | |
| Max power | 48.41 hp 36.1 kW |
| Fuel use | 5.6 gal/hour 21.2 l/hour |
| Gear 2H used for power test. | |
| Max pull | 7515 lbs 3408 kg |
| Gear 1L used for pull test. | |
